GYFTA53
Product Structure:
Product Description:
GYFTA53 (Loosetube stranding, Non-metal strength member, Flooding jelly compound, Aluminum-polyethyleneadhesive inner sheath, Steel-polyethylene adhesive outer sheath)
Standards:
YD/T 901-2009Outdoor layer stranded optical cable for telecommunications
Technical Parameters(Typical Value):
Fiber Count | Structure | Diameter (mm) | Weight (kg/km) | Tensile(N) Long Short term term | Crush(N) Long Short term term | Bending Radius(mm) Static Dynamic |
2-30 | 1+6 | 13.8 | 176 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
32-36 | 1+6 | 13.8 | 176 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
38-60 | 1+6 | 14.7 | 198 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
62-72 | 1+6 | 14.8 | 199 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
74-84 | 1+7 | 15. 2 | 212 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
86-96 | 1+8 | 16. 1 | 233 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
98-108 | 1+9 | 17. 0 | 257 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
110-120 | 1+10 | 17. 7 | 278 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
122-132 | 1+11 | 18. 5 | 304 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
134-144 | 1+12 | 19. 2 | 326 | 1000 | 3000 | 1000 | 3000 | 12.5D | 25D |
Note 1.D refers to the cable diameter;
2.The relevant technical Parameters canbe adjusted according to the customer’s demands;
3.The block water way can be adjustedaccording to the customer’s demands;
4.The design flame resistance,anti-rodent, termite resistant cable according to the customer’s demands.
